CIAM PRODUCTS- Original product
Description
BUZZER ASY-TURN INDICATOR
WORKING CHARACTERISTICS
Water and dust protection: IP30 - Working and storage temperature: - 40°C / +80°C - Buzzer unit shall begin to sound in phase with the flasher unit after 28" -/+ 5% - Buzzer unit will sound
continuously with key switch on and handbrake pulled. Handbrake is predominant on flasher unit.
WORKING CHARACTERISTICS
Water and dust protection: IP30 - Working and storage temperature: - 40°C / +80°C - Buzzer unit shall begin to sound in phase with the flasher unit after 28" -/+ 5% - Buzzer unit will sound
continuously with key switch on and handbrake pulled. Handbrake is predominant on flasher unit.
RATED VOLTAGE
12V
ABSORBED CURRENT
88,2 mA - /+ 10% @ Vcc=13,5Vdc
MINIMUM SOUND PRESSURE CM.60
75 Db a 1metro/metre @ saej994
OPERATING FREQUENCY
2048 Hz - /+ 5%
APPLICATIONS
Components for access platforms telescopic - cranes
Telehandlers
Forklift trucks
Earth moving machines
Trucks tractors - trailers
Agricultural vehicles
Combines
Mixer wagons
Fire fighting - rescue vehicles
Camper & caravan
Motorcycles - quad components
Electric vehicles - golf cart
Can-bus boat global control system
Ambulances - emergency vehicles
Defense vehicles
1030353
Code: 31.025.000.01
Doc. Code: 31-025-000-01
