CIAM PRODUCTS- Original product
Description
ELECTRONIC BUZZER RELAY
WORKING CHARACTERISTICS
Temperature: - working temperature: - 30°C to +80°C - Stocking temperature: - 40°C to +85°C it will maintain its working characteristics - Resistance to constant humidity: HR 98 % at 40°C - 96%
HR : permanent without changes of working characteristics - Vibrations: acceleration: 56 - Analyze at variable speed: 10a 200 Hz and 200 Hz at 10 Hz - Period: 2min/analyse - Time: 24hr (hours) on each axe
WORKING CHARACTERISTICS
Temperature: - working temperature: - 30°C to +80°C - Stocking temperature: - 40°C to +85°C it will maintain its working characteristics - Resistance to constant humidity: HR 98 % at 40°C - 96%
HR : permanent without changes of working characteristics - Vibrations: acceleration: 56 - Analyze at variable speed: 10a 200 Hz and 200 Hz at 10 Hz - Period: 2min/analyse - Time: 24hr (hours) on each axe
POWER SUPPLY VOLTAGE V
12
WORKING VOLTAGE
10-16V
CONSUMPTION
< 1,5 mA - 13,5V
MINIMUM SOUND PRESSURE CM.60
65db lin 25 cm. sotto/under 13V
APPLICATIONS
Components for access platforms telescopic - cranes
Telehandlers
Forklift trucks
Earth moving machines
Trucks tractors - trailers
Agricultural vehicles
Combines
Mixer wagons
Fire fighting - rescue vehicles
Camper & caravan
Motorcycles - quad components
Electric vehicles - golf cart
Can-bus boat global control system
Ambulances - emergency vehicles
Defense vehicles
1003695
Code: AV.18.0040.01
Doc. Code: AV-18-0040
