The image shown here is for illustrative purposes only.
START SWITCH
Code: 14.130.000.11
Doc. Code: 14-130-000
€42.00
Tax excluded
(51.24 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
description
| key position | connection | max current 12v | max connec. time | function |
|---|---|---|---|---|
| 0 | ||||
| 1 | 30/1-15 | 20 a | inf. | gear |
| 2 | 30/1-15 | 20 a | inf. | gear/preheating |
| 2 | 30-15/54 | 25 a | 1 min. | |
| 3 | 30/1-15 | 20 a | inf. | gear/preheating/start |
| 3 | 30-15/54 | 25 a | 1 min. | |
| 3 | 30-50 | 50 a | 1 min. |
type contact
break contact mechanism
key removable
only in position 0
