Electronic dynamometer composed by an aluminum traction load cell where is placed an electronic with a LCD display 5 digit h=1,7 cm, designed for traction static forces measurement and static loads.. Functions are provided for: digital zero and weight settings, digital filter selection (greater attenuation of weight oscillations), automatic power-off selection, peak function and Hold function and measuring units selection (kg – N – kN - lb).
INCLUDED IN THE SUPPLY: - PVC carrying case.
NOTE - The crickets are included in the price only for capacities of 2.5t - 3.2t - 5t and 6.3t; - The ns. laboratory is able to perform calibrations with traceability credited up to 50t; - For dynamometers with a higher flow rate, if calibration is required up to the nominal capacity, it must be quoted separately and carried out by an external specialized body.
MAIN FEATURES Tare reset and load recovery Lock-release of the displayed load Acquisition of the maximum load achieved Indication of gross, net and tare weight Selection of the unit of measurement (kg—> t—> ton—> Lbs—> daN—> kN) Selection of reading speed Auto-off enable Zero and weight calibration LCD display with 5 digits 17 mm high Standard 9V battery (200h battery life) Choice of unit of measure (kg—> t—> ton—> Lbs—> daN—> kN) Resetting the keyboard tare Peak measurement function Overload indication on the display (110% f.s.) Display speed of the measurement that can be set from the keyboard
APPLICATIONS
Components for access platforms telescopic - cranes
