The image shown here is for illustrative purposes only.
STEERING COLUMN SWITCH 2000 SERIES
Code: 01.0860.0000.01
Doc. Code: 01-0860-0000-01
€392.89
Tax excluded
(479.33 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
description
| function | peak load 12v | peak load 24v |
|---|---|---|
| low beam | 15a | 7a |
| high beam | 6a | 3a |
| flashing | 6a | 3a |
| direction | 6a | 3a |
| windscreen washer | 3a | 1,5a |
| position light | 3a | 1,5a |
| work lamp | 3a | 1,5a |
| forward gear | 200ma | 100ma |
| neutral | 200ma | 100ma |
| reverse gear | 200ma | 100ma |
| speed 1 | 200ma | 100ma |
| speed 2 | 200ma | 100ma |
| switch | 3a | 1,5a |
length lever mm
201-300
steering height mm
0-100
length lever 1 mm
201-300
steering height 1 mm
0-100
fixing
column 45 mm
type
doppio
technology
frontali in aria
type connection
deutsch 12 vie
deutsch 12 vie
deutsch 4 vie
length lever mm detail
234
steering height mm detail
85
length lever 1 mm detail
234
steering height 1 mm detail
84
model type
serie 2000
function - low beam
attivo
function - high beam
attivo
function - flashing
attivo
function - direction
attivo
function - rientro automatico
attivo
function - windscreen washer
attivo
function - main lighting
attivo
function - forward gear
attivo
function - neutral
attivo
function - reverse gear
attivo
function - speed 1
attivo
function - speed 2
attivo
function - work lamp
attivo
function - switch
attivo
