STEERING COLUMN SWITCH

COBO (Original product)
1007539

Code: 01.419.000.01

Request quotation
Add to Wishlist
  • SSL 100% secure website SSL 100% secure website
  • Fast shipping with national and international couriers Fast shipping with national and international couriers
Sito sicuro | Pagamento sicuro
Description
FUNCTIONPEAK LOAD 12VPEAK LOAD 24V
HORNS5A3A
LOW BEAM6,5A4,5A
HIGH BEAM7A5A
FLASHING7A5A
DIRECTION7A5A
WINDSCREEN WASHER9A6S
INTERMITTENT WIPERS5A3A
WINDSCREEN WIPER 11,8A1A
WINDSCREEN WIPER 28A5A
FORWARD GEAR2A1A
NEUTRAL5A3A
REVERSE GEAR5A3A
LENGTH LEVER MM
201-300
STEERING HEIGHT MM
0-100
CONNECTION LENGTH MM
801-900
LENGTH LEVER 1 MM
201-300
STEERING HEIGHT 1 MM
0-100
CONNECTION LENGTH 1 MM
801-900
FIXING
COLUMN 38 MM
TYPE
DOPPIO
TECHNOLOGY
MICROSWITCH
LENGTH LEVER MM DETAIL
222
STEERING HEIGHT MM DETAIL
78
CONNECTION LENGTH MM DETAIL
900
LENGTH LEVER 1 MM DETAIL
247
STEERING HEIGHT 1 MM DETAIL
96
CONNECTION LENGTH 1 MM DETAIL
900
MODEL TYPE
SERIE 240
FUNCTION - HORN
Attivo
FUNCTION - LOW BEAM
Attivo
FUNCTION - HIGH BEAM
Attivo
FUNCTION - FLASHING
Attivo
FUNCTION - DIRECTION
Attivo
FUNCTION - RIENTRO AUTOMATICO
Attivo
FUNCTION - WINDSCREEN WASHER
Attivo
FUNCTION - INTERMITTENT WIPERS
Attivo
FUNCTION - WINDSCREEN WIPER 1
Attivo
FUNCTION - WINDSCREEN WIPER 2
Attivo
FUNCTION - FORWARD GEAR
Attivo
FUNCTION - NEUTRAL
Attivo
FUNCTION - REVERSE GEAR
Attivo
FUNCTION - BLOCK
Attivo
APPLICATIONS
Components for access platforms telescopic - cranes
Telehandlers
Forklift trucks
Earth moving machines
Trucks tractors - trailers
Agricultural vehicles
Combines
Mixer wagons
Fire fighting - rescue vehicles
Camper & caravan
Motorcycles - quad components
Electric vehicles - golf cart
Can-bus boat global control system
Ambulances - emergency vehicles
Defense vehicles
