The image shown here is for illustrative purposes only.
STEERING COLUMN SWITCH
Code: 01.1073.0000.01
Doc. Code: 01-1073-0000-01
€194.40
Tax excluded
(237.17 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
description
| function | peak load 12v | peak load 24v |
|---|---|---|
| horn | 5a | 2,5a |
| low beam | 7a | 3,5a |
| high beam | 7a | 3,5a |
| flashing | 7a | 3,5a |
| direction | 7a | 3,5a |
| windscreen washer | 5a | 2,5a |
| windscreen 1 | 5a | 2,5a |
| windscreen 2 | 5a | 2,5a |
| intermittent s | 5a | 2,5a |
length lever mm
201-300
steering height mm
0-100
connection length mm
801-900
fixing
column 45 mm
type
single
fitting position
lh
technology
frontali in aria
length lever mm detail
247
steering height mm detail
96
connection length mm detail
870
model type
serie 240
function - horn
active
function - low beam
active
function - high beam
active
function - flashing
active
function - direction
active
function - automatic return
active
function - windscreen washer
active
function - intermittent s
active
function - windscreen 1
active
function - windscreen 2
active
