descriptionmulti-channel rxdi02 handheld
rxdi02 is a hand receiver instrument which can receive 433,92 and 868 mhz frequencies. this receiver is equipped with a numeric led display 5 digits (12mm height) and with a 3 mechanical buttons keyboard for the parameters setup and the operational functioning. it’s also available the rs232 communication interface.

connections
serial rxd
serial gnd
supply
no. 3 "aa" type batteries
max. absorption
0,05 va
autonomy
150 hours max
isolation
iii
operating temperature
-10 ° c / + 50 ° c (max 85% humidity without condensation)
storage temperature
-20°c / +60°c
weight display
numeric with 5 digit lcd 7-segment (h = 12 mm)
keyboard
with 3 multi-function buttons
overall dimensions
68mm x 110mm x 31mm (l x h x p)
container material
plastic
degree of frontal protection
ip64
input sensitivity
1 μv min.
linearity
<0.08% of the full scale
drift in temperature
<0.01% of full scale / °c
internal resolution
16 bit
measuring range
2mv/v
weight acquisition frequency
2 hz
digital filter
selectable 0.1 hz - 2 hz
reception frequency
selectable multichannel on reference frequency 868, 3 mhz
serial port
rs232 in transmission
compliance with regulations
en6100-6-3, en61000-6-2, en61010-1
