The image shown here is for illustrative purposes only.
ROCKER SWITCH
Code: 17.194.000.11
Doc. Code: 17-194-000-11
€69.00
Tax excluded
(84.18 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
description
| rated voltage | max direct current (a) | peak current 5" (a) | sealing (iec 529) | operating temperature (°c) | n° life cycles |
|---|---|---|---|---|---|
| 12 v nc | 12 a resisitivi / resistive | 30 a | ip 66 | -20°c ÷ +40°c | 100.000 |
| 12 v no | 8 a induttivi/inductive | 30 a | ip 66 | -20°c ÷ +40°c | 100.000 |
| 24 v nc | 8 a resisitivi / resistive | 20 a | ip 66 | -20°c ÷ +40°c | 100.000 |
| 24 v no | 12 a induttivi/inductive | 20 a | ip 66 | -20°c ÷ +40°c | 100.000 |
switch mode
momentary
