CONTROL SYSTEM
Freescale iMx6 Dual Core, 32 bit
- Frequency 850 Mhz
- Internal memory 8 GB flash
- RAM memory 1 GB
- Wake-up mode: Power supply, CAN message, ignition key
- Tempo di boot: < 1 sec from stdby, about 10 sec from cold boot
- Internal sensor temperature: YES
- Internal accelerometer / gyroscope: YES
- Keys: 4+4 softkeys on front panel, 1 softkey programmable also as ON/OFF (KEYS VERSION)
- Buzzer: 100 dB, volume adjustable
- CAN bus port: 4
- RS232: 1 port full modem, 1 port linux terminal
- USB port: 1 HOST external (KEYS VERSION), 2 HOST on connector, 1 OTG Device on connector
- Video INPUT: 2 PAL/NTSC simultaneos
- Connector: 2 x AMP automotive 26 pin (signal), 1 x M12 8 pin (video camera)
- Operative system: Linux, Android
- Standards: EMC industrial, automotive, agriculture, ISO 11783 (ISOBUS UT+TC)
- Programming languages: C, C++, QT/ QML
- Programming IDE: VT3, QT CREATOR
