The image shown here is for illustrative purposes only.
TERA 12 HE DISPLAY NO KEYS HIGH OUTDASH
Code: 1084268
CONTACT US FOR MORE INFORMATION
(0 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
descrizione tera12 he is the high end display solution for off- highway market. it runs with the latest freescale imx6tm processor, that joins strong multimedia capabilities and graphics management.
applicazioni
it allows 3d graphics, multitouch capacitive touchscreen, tablet-style looking, always keeping the industrial standards at base of design.
applicazioni
- high size telescopic or lattice boom cranes
- harbor cranes
- compactors and municipalities
- foundation machines
- terminal isobus ut for tractors
- fire fighting machines
power supply voltage
8 - 32v
operative temperature
- 30° c ÷ + 65° c
sealing
ip65
display tft
display tft 12.1"
- resolution: 1280 x 800 pixel
- display mode: 16;9, portrait/landscape
- luminosity: 500 cdm
- touchscreen: capacitive with bonding technology
- rtc: si
- resolution: 1280 x 800 pixel
- display mode: 16;9, portrait/landscape
- luminosity: 500 cdm
- touchscreen: capacitive with bonding technology
- rtc: si
control system
freescale imx6 dual core, 32 bit
- frequency 850 mhz
- internal memory 8 gb flash
- ram memory 1 gb
- wake-up mode: power supply, can message, ignition key
- tempo di boot: < 1 sec from stdby, about 10 sec from cold boot
- internal sensor temperature: yes
- internal accelerometer / gyroscope: yes
- keys: no keys (no keys version)
- buzzer: 100 db, volume adjustable
- can bus port: 4
- rs232: 1 port full modem, 1 port linux terminal
- usb port: 1 host external (keys version), 2 host on connector, 1 otg device on connector
- video input: 2 pal/ntsc simultaneos
- connector: 2 x amp automotive 26 pin (signal), 1 x m12 8 pin (video camera)
- operative system: linux, android
- standards: emc industrial, automotive, agriculture, iso 11783 (isobus ut+tc)
- programming languages: c, c++, qt/ qml
- programming ide: vt3, qt creator
- frequency 850 mhz
- internal memory 8 gb flash
- ram memory 1 gb
- wake-up mode: power supply, can message, ignition key
- tempo di boot: < 1 sec from stdby, about 10 sec from cold boot
- internal sensor temperature: yes
- internal accelerometer / gyroscope: yes
- keys: no keys (no keys version)
- buzzer: 100 db, volume adjustable
- can bus port: 4
- rs232: 1 port full modem, 1 port linux terminal
- usb port: 1 host external (keys version), 2 host on connector, 1 otg device on connector
- video input: 2 pal/ntsc simultaneos
- connector: 2 x amp automotive 26 pin (signal), 1 x m12 8 pin (video camera)
- operative system: linux, android
- standards: emc industrial, automotive, agriculture, iso 11783 (isobus ut+tc)
- programming languages: c, c++, qt/ qml
- programming ide: vt3, qt creator
