The image shown here is for illustrative purposes only.
T
Code: 18.0127.0000.02
Doc. Code: 18-0127-0000-02
Pack 50 pieces.
€2,892.50
(€57.85 Cad.)
Tax excluded
(3528.85 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
description
working
- when the control unit switches on, the output (pin 53s) is open.
- when the input is activated (pin t=+12v), the relay is energized
and the output is activated at +12v.
- after 30 sec the output is deactivated. if during this 30-sec
time other pulses get to the input, these are ignored.
- after 30 sec any change of input state doesnt change output state.
- when the control unit switches on, the output (pin 53s) is open.
- when the input is activated (pin t=+12v), the relay is energized
and the output is activated at +12v.
- after 30 sec the output is deactivated. if during this 30-sec
time other pulses get to the input, these are ignored.
- after 30 sec any change of input state doesnt change output state.
power supply voltage v
12v
max load
5 a
delay
30s
