CIAM PRODUCTS- Original product
description
working
- when the control unit switches on, the output (pin 53s) is open.
- when the input is activated (pin t=+12v), the relay is energized
and the output is activated at +12v.
- after 180 sec the output is deactivated. if during this 180-sec
time other pulses get to the input, these are ignored.
- after 180 sec any change of input state doesnt change output state.
- when the control unit switches on, the output (pin 53s) is open.
- when the input is activated (pin t=+12v), the relay is energized
and the output is activated at +12v.
- after 180 sec the output is deactivated. if during this 180-sec
time other pulses get to the input, these are ignored.
- after 180 sec any change of input state doesnt change output state.
power supply voltage v
12v
max load
5 a
delay
180s
APPLICATIONS
Components for access platforms telescopic - cranes
Telehandlers
Forklift trucks
Earth moving machines
Trucks tractors - trailers
Agricultural vehicles
Combines
Mixer wagons
Fire fighting - rescue vehicles
Camper & caravan
Motorcycles - quad components
Electric vehicles - golf cart
Can-bus boat global control system
Ambulances - emergency vehicles
Defense vehicles
1027051
Code: 18.0139.0000.02
Doc. Code: 18-0139-0000-02
Pack 5 pieces.
