CIAM PRODUCTS- Original product
description
isobus speed converter tranforms can messages related to speed into real electrical signals according to iso11786 standard (isobus).
| inputsoutputs | configuration | nr. i/o |
|---|---|---|
| inputs | ||
| outputs | true ground speed | 1 |
| segnale in frequenza ad onda quadra: | ||
| frequency signal square wave: | ||
| frequenza max : 3.125 hz, duty cycle: 20% - 80% | ||
| outputs | theoretical ground speed | 1 |
| segnale in frequenza ad onda quadra: | ||
| frequency signal square wave: | ||
| frequenza max : 3.125 hz, duty cycle: 20% - 80% | ||
| outputs | pto rotational speed | |
| segnale in frequenza ad onda quadra: | ||
| frequency signal square wave: | ||
| frequenza max : 250 hz, duty cycle: 20% - 80% | ||
| outputs | workin/workout | |
| digital output on/off | ||
| outputs | implement position | 1 |
| analogue output: 0 -10 v (3k load) |
microcontroller cpu
freescale, 16 bit, 40 mhz
ram memory
4kb
flash memory
64kb
eeprom memory
4kb
real time clock rtc
no
power supply voltage v
9-16v
load dump protection
yes
can bus
1 can-bus, 2.0b high speed, 11 or 29 bit identifier ,iso 11898-2 compliant
storage temperature
from - 40 °c to +80 °c from - 40 °f to +176 °f
operating temperature
from - 40 °c to +80 °c from - 40 °f to +176 °f
sealing iec 529
ip66
housing
abs enforced pa66
connector
1 x 24 poles automotive
goretex valve
no
dimensions mm
123.5 x 80 x 35 mm
weight
100 g
installation
horizontal/vertical, 3 screws
ce standard
iso 7637 ; 2009/64/ce
isobus standard
iso11786 parts of 5.6, 5.7 standard
